RotorWay Exec 162F - Rotor Hub Assembly Maintenance

RotorWay International
Exec 162F Maintenance Manual
47
Rev. 1 6/04
Section 19: Rotor Hub
The rotor hub system is comprised of three sub-assemblies: the rotor hub assembly, the swash plate and the main shaft.
It comes from the factory as a completed assembly.
Reference prints: E23-2000, E49-2000, E49-2001 E49-2002
INSPECTION CHART
PART NO.
Rotor Hub Assembly
E49-6141 Rotor Hub Plate 100 HR 1000 HR 19-1
E49-5100 Teeter Block Assembly 100 HR 1000 HR/OC 19-2
E49-5110 Teeter Block Bearing 100 HR 500 HR 19-2
E49-6281 Delrin Shim 100 HR OC 19-1,3
E49-6341 Stainless Steel Shim 100 HR OC 19-1,4
E00-2607 AN176-22A (3/8 x 2-1/4) Bolt 100 HR 2000 HR/OC Torque
E49-6301 Main Rotor Drive Pin 100 HR 250 HR/OC 19-1,5
E00-4802 Thin Washer 100 HR 1000 HR
E49-5131 Snap Ring 100 HR 100 HR/OC
E49-6200 Thrust Blocks (M-S) 100 HR 2000 HR/OC
E49-6210 Thrust Washer 100 HR 2000 HR
E49-1340 Thrust Block Alignment Bearing 100 HR 100 HR/OC 19-6
E49-1360 Thrust Block Liner 100 HR 2000 HR/OC
E49-1170 Rod End (Left Hand) 100 HR 1000 HR/OC
E49-1190 M/R Blade Pitch Link 100 HR 1000 HR/OC
E00-9300 Set Screws 1/4 x 1/4 100 HR 1000 HR Torque
E00-9301 Set Screws 1/4 x 5/8 100 HR 1000 HR Torque
E00-9305 Set Screws 1/4 x 3/16 100 HR 1000 HR Torque
E49-6310 Pitch Pin (Outboard) 100 HR 100 HR/OC 19-7
E49-6320 Pitch Pin (Inboard) 100 HR 100 HR/OC 19-7
E00-2417 NAS-428-4-20 (1/4 x 2) Bolt, Full Thread 100 HR 1000 HR/OC 19-8
E00-2523 AN5-32A (5/16 x 3-1/4) Bolt 100 HR 1000 HR/OC 19-9
E49-7000 Main Shaft 100 HR 1000 HR/OC 19-10
E49-5140 Grease Fitting 25 HR 2000 HR 19-11
E49-1331 Dust Cap 100 HR 2000 HR
Swash Plate Assembly
E49-3610 Non-Rotating Swash Plate 100 HR 2000 HR/OC F
E49-3520 Swash Plate Bearing 100 HR 2000 HR/OC F
E49-3541 Snap Ring, Non-Rotating Swash Plate 100 HR 2000 HR/OC F
E49-3510 Rotating Swash Plate 100 HR 2000 HR/OC F
E49-3230 Slider Ball Adjustment Collar 100 HR 2000 HR/OC 19-12
E49-4010 Cyclic Cable Mount 100 HR 2000 HR/OC F
E49-4100 Cyclic Mount Bearing 100 HR 2000 HR/OC F
E49-4110 Snap Ring Cyclic Mount 100 HR 2000 HR/OC F
E49-3531 Snap Ring, Rotating Swash Plate 100 HR 2000 HR/OC F
E49-3210 Collective Slider Ball 100 HR 1000 HR/OC 19-13
E49-3220 Spherical Bushing 100 HR 1000 HR/OC
E49-1530 Slider Ball Clamp 50 HR 2000 HR/OC 19-13
E49-1520 Slider Ball O-ring 100 HR 1000 HR/OC
F
E49-3240 Snap Ring, Slider Ball 100 HR 1000 HR F
E00-9302 Set Screw (10-32) 100 HR 2000 HR Torque
F = Factory Service Item
DESCRIPTION
SERVICE
REFERENCE
INSPECTION
INTERVAL
R.C.O.
