Exec 162F Maintenance Manual

HOURLY SERVICE CHART EXEC 162F

REFERENCE SECTION 5: TAIL ROTOR

PART NO. DESCRIPTION 25 50 100 200 250 500 1000 1500 2000

E17-1260 FS3 PP Bearing I R

E17-1290 Snap Ring I R

E00-2604 AN6-24A (3/8 x 2-1/2) Bolt I R

E17-6126 Carriage Slider Assembly I R

E17-1300 Carriage Slider Bearing I R

E17-1210 Rod End 5/16 Teflon I R

E17-6000 Tail Rotor Blade Assembly I R

E17-5120 Pitch Actuator Arm Pivot Casting I R

E17-1340 Bearing Assembly I R

E17-5110 Pitch Horn I R

E17-9010 Slider/Actuator Arm Clevis I R

E17-6150 Tail Rotor Shaft I R

E17-1360 Bearing Plate Slider Rail I R

E17-5101 Tail Rotor Pulley I R

E16-1200 Female Rod End I R

E17-1270 Alignment Bearing Assembly I R

E17-1280 Thrust Bearing Assembly I R

E17-6100 Tail Rotor Barrel I R

I INSPECT

R REPLACE

Rev. 1 6/04
