HOURLY SERVICE CHART EXEC 162F

REFERENCE SECTION 10: DRIVE TRAIN

PART NO. DESCRIPTION 25 50 100 200 250 500 1000 1500 2000

E49-6172 Main Sprocket I R

E49-7010 Sprocket Hub I R

E00-2608 AN176H (3/8 x 3-1/8) Bolt I R

E00-2450 AN4H12 (1/4 x 1-1/4) Bolt I R

E00-3410 Thin Locknut I R

E00-9028 Hose Clamp I R

E24-5110 Upper Engine Mount Clevis I R

E24-5100 Upper Engine Mount Cup I R

E23-1002 Secondary Pulley Assembly I R

E23-5001 Upper Bearing Assembly I R

E23-6125 Secondary Shaft I R

E23-2552 Lower Bearing I R

E23-1210 Main Drive Belts I R

E23-7141 High Temp Fan I R

E23-1170 Snap Ring IR

E23-3001 Fan Pulley Assembly I R

E23-1221 Fan Pulley Bearing R

E23-6191 Retainer Plate IR

E33-7101 Top Rear Cover I

E33-7121 Lower Oil Bath Pan I

E33-7111 Top Front Cover I

E33-1170 Rear Oil Seal Assembly I R

E33-1140 Tension Spring I R

E33-3000 Rain Shield I R

E49-1290 Drive Chain W/Link I R

E27-6100 Idler Pulley Assembly I R

E27-1231 Idler Pulley Bearing I R

E27-1160 Rod End I R

E27-1210 Idler Spring I R

E27-2160 5/16 Rod End I R

E27-9020 Clutch Tube Weldment I R

E27-9010 Pulley Arm Weldment I R

E27-5100 Clutch Arm Casting I R

E00-2522 AN5-30A (5/16 x 3) Bolt I R

I INSPECT

R REPLACE
