rotowash R20 - Fitting the Cables; Fixing the Main Cable; Cable Safety

Fitting the cables
A, S
Fit the electrical plug from machine
into the correct socket.
Machine  motor socket
B
Fit the electrical plugs from machi
ne
and pump into the correct sockets.
Spraying unit  pump socket
Machine  motor socket
Pump Motor
Fixing the main cable
Push the mains cable into the
purpose-made hooks on the
handle. This will avoid the cable
being run over by the revolving
brushes
Cable safety
Place for an extra protection the
main cable in the cable safety.
Push the mains cable into the
purpose-made hooks on the
handle. This will avoid the cable
being run over by the revolving
brushes
Mains
supply
Spraying
unit
Machine
