Rotronic RMS - Technical Specifications

RMS-LOG Wireless / LAN Data Loggers
E-M-RMS-MLOG-868-V1_0.docx
Instruction Manual
8 Technical Specifications
General
Device type
RMS Mini Data Logger
Measured parameters
• Temperature (NTC)
• Temperature (NTC) & light
• Voltage
• Current
• Switch contact
IP protection class
IP65
Range of application
-40..85 °C / 0..100 %RH
Storage and transport conditions
-40..30 °C / 0..95 %RH
Data memory
10,000 measured values
Interfaces
Wireless 868 MHz
Wireless range
20..50 m, indoors
Power supply
Supply voltage
Battery
Polarity protection
Yes
Battery life
3 years
(at 23 °C and interval of 1 minute)
Start Time and Measurement Interval
Start time
Wireless logger: 1 s (typical)
Measurement interval
10 s to 15 min.
Housing Specifications
Housing material
ABS
Dimensions
83 x 29 x 29 mm
Weight
100 g
© 2016  ROTRONIC AG  Bassersdorf  Switzerland Page 18 of 22
