RMS-LOG Wireless / LAN Data Loggers
E-M-RMS-MLOG-868-V1_0.docx
Instruction Manual
1.6 RTCC (Real Time Clock Calendar)
The device has a real time clock calendar. The time is synchronized continuously when connected to the server.
1.7 Data Logging and Measurement Interval
The values of every measurement are saved in the memory with the time-stamp. At a measurement interval of
one minute, it is possible to save data of one month, which corresponds to 10,000 pairs of measured values.
When the ring memory is full, the oldest values are overwritten.
1.8 Indicator and Button
The device has a button and multicolour LED for use and indication of the operating state. The button is used
to start the device or switch it off in battery mode. The LED indicates the device status and whether it was
possible in the current measurement interval to carry out a valid measurement and send the data to the
monitoring system.
LED Status Indicator
Connected
Flashes green when
button pressed
1 time: very weak reception
2 times: weak reception
3 times: good reception
4 times: very good reception
Flashes red
1 time: low battery, replace soonest
2 times: temperature sensor not connected
Not connected
pressed
Flashes quickly
Device waiting for integration into the software
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 7 of 22
