190
Engine Compartment
2.0 & 2.5 PETROL ENGINE
While working in the engine compartment, always observe the safety precautions listed
under ‘SAFETY IN THE GARAGE’, page 187.
H2837a
1
2
3
4
5
6
1. Engine oil dipstick (yellow)
2. Brake reservoir (black cap)
3. Engine oil filler (yellow cap)
4. Cooling system reservoir
5. Power steering reservoir (black cap)
6. Washer reservoir (blue cap)
