seat cover. These optional armrests also have a built-in height adjustment knob that can be used to
adjust the arm pad to a comfortable level for the driver (Item A - Figure 10).
Backrest Angle A
The backrest can be adjusted from 94º to 118º.
This can be accomplished by pulling up on the backrest
adjustment handle (Item B - Figure 10).
Adjustable Footplate
The length and height of the footplate can be adjusted to B Figure 10
maximize your comfort and stability. To adjust the height
of the footplate, loosen and remove the bolt (Item C-
Figure 11), adjust to height and replace. To adjust the
length of the footplate, loosen the allen bolt on both sides
D
of the base (Item D-Figure 11), adjust the length, and tighten.
Front and Rear Battery Access
Refer to “Battery Access” - Maintanance Section Figure 11 C
for more information.
Seat Position Adjustment
WARNING: The seat position fore/aft (Forward/Rearward) has been set for optimal stabil-
ity from the factory. Modifying the seating position to a location other than has been set from the
factory could reduce the stability of the powered wheelchair, resulting in serious injury.
CAUTION:TheseatheightshouldbeadjustedbyanauthorizedROVI
®
provider only.
Alternate Seating Options
The ROVI
®
X3 can accommodate Complex Power Rehab Seating configurations that are available
from Motion Concepts. For more information regarding Motion Concepts seating and positioning
products, please visit www.motionconcepts.com.
