ROYAL ENFIELD 350cc O.H.V. WORKSHOP MANUAL
Page 6
DATA-continued
CARBURETTER.
Type and Number .......... .......... ... ....... .......... Amal. 276 AC/1A
Main Jet Size .................. ... ....... ... ....... ... ....... ... ....... ... ........ 130
Throttle Valve ................ ... ....... ... ....... ... ....... ... ....... ... ........ 6/4
Taper Needle located by clip in third notch from top.
IGNITION.
Contact Breaker Maximum opening ... ... ... .012 in.
Ignition Setting ... ... ... ...
3
/
8
in. before t.d.c.
= 34° advance.
Sparking Plug-Size ................... ... ....... ... ... 14 m.m.
1
/
2
in. reach.
Type .......................................... ... ....... ... ..... Lodge C.14 Sintox.
................................................... .......... ....... or Champion L.10S.
Gap Setting ............................... .......... ... .018 in. to .020 in.
GENERAL.
Petrol Tank Capacity 2
3
/
4
gallons (including
1
/
4
gallon reserve).
Oil Tank Capacity ... ... ... ... ... 4 pints.
Gear Box Capacity ... ........ .. ....... ... ....... ... ....... ... ...
3
/
4
pint.
TOOLS SUPPLIED WITH MACHINE
TOOL ROLL AND CONTENTS
No. per Part Description.
Set No.
1 28996 Swivel Pin and Chain Adjuster Spanner
(to fit 5/16" square).
1 16008 Magneto Spanner (.255" x .283" hex.
with .012" feeler).
1 29101 Pump Cover Pin Spanner (.255" hex.
with .018" feeler).
1 4272 Tyre Lever (cranked type).
2 4272A Tyre Levers (spoon type).
1 3482 Screwdriver, 6", wire.
1 14835 Extractor Nut (Dynamo Pinion).
1 16014 Grease Gun.
1 16007 Tool Roll (with strap-less tools).
4 25861 Hallite Washers for Push Rod Tubes.
No. per Part Description.
Set No.
1 29044 Double-ended Spanner-Engineers' Patt.
(1/4" x 5/16" Whit.)
1 2976 (3/8" x 7/16" Whit.)
1 24092 .380" x .343" hex.
-also .380" sq.)
2 24096 (3/16" x 1/4" Whit.)
1 28976 Tubular Spanner (1/4" Whit.)
(For Cylinder base nuts)
1 16594 (9/16" Whit.)
1 21166 (7/16" Whit.)
1 24094 (11/16" Whit.)
1 29043 (3/16" Whit.)
1 24097 (5/16" x 3/8" Whit.)
1 29042 Tommy Bar (Bent)
SUPPLEMENTARY KIT
1 27388 Chain Rivet Extractor.
1 27387 Tyre Repair Outfit.
1 29382 Box of Spare Links (5/8" pitch chain).
1 27383 Packet of insulating Tape.
2 27386 Leather Straps.
1 27528 Oil Can.
1 27389 Oil Funnel.
1 27575 Pliers, 7".
1 27574 Adjustable Spanner, 7".
1 27576 Screwdriver, 6".
