Royal Enfield Himalayan User Manual

Royal Enfield Himalayan 19
RECOMMENDED LUBRICANTS
* Do not mix DOT 4 or other brake fluid together.
NOTE
1. Coolant from Total is ready to use and does not require mixing.
2. Recommendation subject to change without notice.
3. The above values are approximate and the actual capacity will vary.
CAUTION
Use of wrong oil grade will reduce the life of the moving parts and seriously affect performance.
ENGINE OIL COOLANT FRONT FORK OIL BRAKE FLUID
Grade 10W40 API SN, JASO MA2, Semi Synthetic
TOTAL COOLELF AUTO
SUPRA -37 ºC
SS-47G DOT 4*
Capacity
1
st
dry fill: 2.4 L
Radiator:
Dry fill - 915 ml
Service fill - 815 ml
RH fork: 589 ± 2.5 ml Front - 90 ± 5 ml
Refill: 2.1 L for oil service
(Including filter change)
Expansion Tank:
Fill to max mark - 240 ml
LH fork: 507 ± 2.5 ml Rear - 80 ± 5 ml

Royal Enfield Himalayan Specifications

General

Engine Type	Single Cylinder, 4 stroke, Air cooled, SOHC
Displacement	411 cc
Max Power	24.3 bhp @ 6500 rpm
Max Torque	32 Nm @ 4000 - 4500 rpm
Fuel System	Electronic Fuel Injection
Transmission	5-speed constant mesh
Front Suspension	Telescopic, 41 mm forks, 200 mm travel
Rear Suspension	Monoshock with linkage, 180 mm wheel travel
Front Brake	300 mm disc, 2-piston floating caliper
Fuel Tank Capacity	15 liters
Seat Height	800 mm
Ground Clearance	220 mm
Kerb Weight	199 kg
Bore x Stroke	78 mm x 86 mm
Compression Ratio	9.5:1
Clutch	Wet, multi-plate
Frame Type	Half-duplex split cradle frame
Tyre Size (Front)	90/90 - 21
Tyre Size (Rear)	120/90 - 17
Wheelbase	1465 mm
Rear Brake	240mm disc, single-piston floating caliper
ABS	Dual Channel ABS (Switchable)
