5-2
5.1 READING LCD DATA
An example of information provided by the LCD is shown below:
3 0.0gf
13
NDT78.0g AUT PULLING
The display provides information concerning the most recently completed test, or if a test
is running, the current test.
The test number, the pull force (in grams), and the fail code number are shown across
the top row of the display.
Destruct or non-destruct test mode is indicated in the lower left corner of the display
(“DESTRUCT” or “NDT”). When the system is set to non-destruct mode, the NDT limit
value is displayed next to “NDT”.
Manual or semi-automatic test mode is indicated in the lower middle of the display
(“AUT” or “MAN”).
Test status is indicated in the lower right corner of the display (“READY” or “PULLING”).
