4-2
4.1 READING THE DISPLAY
An example of information provided by the LCD is shown below:
3 0.0gf
13
NDT78.0g AUT PULLING
The display provides information concerning the most recently completed test, or if a test
is running, the current test.
The test number, the pull force (in grams), and the fail code number are shown across
the top row of the display.
Destruct or non-destruct test mode is indicated in the lower left corner of the display
(“DESTRUCT” or “NDT”). When the system is set to non-destruct mode, the user set
NDT limit value is displayed next to “NDT”.
Manual or semi-automatic test mode is indicated in the lower middle of the display
(“AUT” or “MAN”).
Test status is indicated in the lower right corner of the display (“READY” or “PULLING”).
“READY” indicates that the system is ready to begin a test and “PULLING” indicates that
a test is in progress.
4.2 Running tests
The System 610 is capable of manual or semi-automatic pull testing.
4.2.1 Manual Testing
After completion of setup procedures, testing may begin. Position the test hook and
press the center mouse button to begin a test.
4.2.2 Semi Automatic Testing
The System 610 semi-automatic testing mode automates some steps of the testing
procedure. Semi automatic test mode enables the user to set up a test hook position (z
axis and θ) that the system will “remember” and repeat. Once the semi auto setup is
completed, the operator needs only to position the sample and start the test.
