RS PRO RS-14 - Page 5

AC Voltage (Auto-ranging except 200mV)
Resistance (Auto-ranging)
Temperature
Diode Test
DC Current
(Auto-ranging for uA and mA)
AC Current (Auto-ranging for uA and mA)
6 7
Autoranging Multimeter/English Autoranging Multimeter/English
Range Resolution Accuracy
200.0mV 0.1mV +1.5%of rdg + 30 dgts
2.000V 1mV +1.2% of rdg + 3 dgts
20.00V 10mV
+
1.5% of rdg + 3 dgts
200.0V 100mV
600V 1V +2.0% of rdg + 4 dgts
Input Impedance: 10MΩ
Frequency Range:50 to 60Hz
Maximum Input: 600V dc/ac rms.
Overload Protection: 0.2A / 250V and 10A / 250V Fuse.
Frequency Range: 50 to 60 Hz
Maximum Input: 200mA dc or 200mA ac rms on uA / mA ranges, 10A
dc or ac rms on 10A range.
Input Protection: 250V
Sensor: Type K Thermocouple
Overload protection: 250V dc or ac rms..
Open circuit voltage: 1.5V dc typical
Overload protection: 250V dc or ac rms.
Overload Protection: 0.2A / 250V and 10A / 250V Fuse.
Maximum Input: 200mA dc or 200mA ac rms on uA / mA ranges, 10A
dc or ac rms on 10A range.
Range
Resolution
Accuracy
200.0uA
0.1uA
+1.0% of rdg + 3 dgts
2000uA
1uA
+1.5% of rdg + 3 dgts
20.00mA
10uA
200.0mA
100uA
10A
10mA
+2.5% of rdg + 5 dgts
Range
Resolution
Accuracy
200.0uA
0.1uA
+1.5% of rdg + 5 dgts
2000uA
1uA
+1.8% of rdg + 5 dgts
20.00mA
10uA
200.0mA
100uA
10A
10mA
+3.0% of rdg + 7 dgts
Range Resolution Accuracy
200.0Ω 0.1Ω +1.2% of rdg + 4 dgts
2.000kΩ 1Ω +1.0% of rdg + 2 dgts
20.00kΩ 10Ω
+
1.2% of rdg + 2 dgts
200.0kΩ 100Ω
2.000MΩ 1kΩ
20.00MΩ 10kΩ +2.0% of rdg + 3 dgts
Range
Resolution
Accuracy
-50
o
C~+1000
o
C
1
o
C
+3% of rdg +5dgts
-58
o
F~+1832
o
F 1
o
F +3% of rdg +8dgts
Test current Resolution Accuracy
0.3mA
typical
1 mV +
10% of rdg + 5 dgts
