Audio Distribution System
AD-8x
38
Total Output Zones Eight zones, two channels each (either 4 ohm or
8 ohm speakers may be connected to the zone
outputs)
Rated Power /
Channel
>20 Watts, 20Hz to 20KHz
(RMS, 2 channels driven into 8 ohms)
Power / Channel >25 Watts @ 1KHz
(RMS, 2 channels driven into 8 ohms)
Total Harmonic
Distortion
@20W/8ohm
0.5%
Total Harmonic
Distortion
@1W/8ohm
<0.05%
S/N @ Rated power,
IEC A-wtd, Source
input shorted
92dB (mute +1)
Frequency Response
20Hz to 20KHz @
1W/8ohms
1.5+/-0.5dB
Input Overload 2.5V
Input Impedance >22K ohms
Channel Separation
@1KHz
>60dB
Crosstalk Between
Sources @ Rated
Power /1KHz
>75dB
Crosstalk Between
Zones @ Rated
Power /1KHz
80dB
Treble Control
@10KHz
10dB +/- 0.5dB
Bass Control Range
@100Hz
10dB +/- 0.5dB
AUDIO
All specications subject to change without notice.
CHAPTER 4 | SPECIFICATIONS
