CHAPTER 4 | SPECIFICATIONS
Power Supply 115VAC or 230VAC (switchable), 230W
Mounting Rack mount or free standing
Dimensions
(W x H x D)
16.9” (430mm) x 5.3” (133mm) x 14.5” (369mm)
Weight 23.4 lb. (10.6kg)
Warranty One Year (Parts & Labor)
All specications subject to change without notice.
GENERAL
Output Zones Eight zones, two channels each
Pre-Outputs Eight, RCA jack pairs (switchable between xed or
variable)
Audio Source Inputs
(Local)
Eight, 8 RCA jack pairs
Audio Source Inputs
(Remote)
Four, RJ-45 jacks
Loop Outputs Eight, 8 RCA jack pairs
Control Input One, 3.5mm jack, compatible with industry
standard IR repeaters and receivers
Control Output One, 3.5mm jack, compatible with industry
standard IR repeaters and receivers
Remote Source IR
Inputs
Five, Four discrete, One universal (All), 3.5mm
jacks
Mute Input One, 3.5mm jack
Phone Input Sensitivity: AC25V-AC100V 20Hz
Doorbell Sensitivity: AC/DC 3-12VDC
Trigger Output
(Status Jack)
One, 12VDC, 15mA max
+12VDC
Voltage Output
One, 12VDC, 500mA max
RS-232 Port One, Bi-directional DB-9
Ethernet Port
One, 10/100Base-T, RJ45 Connection
Unit ID Numbers 1-8, Set using 3 switches
CONTROL & CONNECTIONS
