VX88-18G USER GUIDE
Technical Support: Support@rticorp.com | Customer Service: CustServ@rticorp.com
27
Schematic
RS-232 HDMI IR CAT Network Connection
Example Schematic VX88-18G
12V PoC
HDMI IR RS-232
SOURCE 01
SOURCE 02
SOURCE 03
SOURCE 04
SOURCE 05
SOURCE 06
SOURCE 07
SOURCE 08
VX88-18G Matrix
AVR
4K Projector
4K Display
IR Emitter
Link to Source
40m Max
(4K)
Control Processor
Max 8 x 4K Displays via HDBaseT
VRX70-18G Receiver
(Sold Separately)
VRX70-18G Receiver
(Sold Separately)
1 2 3 4 5 6 7 8
Maximum of 8 x 4K Sources
