Realtimes Beijing Technology Co.,LTD www.realtimesai.com
Z506-B Reference Manual V1.0
1 Product introduction
Z506-B to one based on NVIDIA Jetson ™ NANO series ™ module design of your new feiyun box,
built-in integration 128 nuclear Maxwel ™ architecture of GPU NANO module, Ubuntu 18.04 operating
system, with 0.5 TFLOPS the AI processing capacity of floating point arithmetic, using super strong light
aluminum alloy material design, transmitting heat, good heat dissipation ability, the overall size is small and
light, good structure of human body engineering, obligate has easy the wing structure of installation, It has the
stable operation capability of 7x24 ultra-long MTBF on site, which can be applied to autonomous machines
such as robots, unmanned delivery vehicles, intelligent gate machines and intelligent sales containers, etc. It is
an ideal carrier for deploying AI computing power for deep learning at the edge.
External interface resources provided by Z506-B include: 1 X GbE,1 x Mini PCIE, 1 x USB3.0, 1 x
USB2.0, 1 x USB OTG,2 x 3.3V UART, 1 x FPD-Link III,1 x MIPI,12 X GPIO(optional),1 X Mini HDMI,1 x
Micro SD, 1 x Micro SIM,4G LTE(optional), the products have passed CCC certification and CE certification
of EU.
1.1 Feature
Compatible with nvidia Jetson NANO module
GPU: NVIDIA Jetson ™ NANO 128 core with NVIDIA Maxwell ™ architecture (472 abbr.giga
floating-point operations per second),
CPU: ARM Cortex-A57 (quad-core)
Operating system: Linux pre-installed
Memory: 4GB LPDDR4
Storage: Built-in 16GB or expandable TF card slot
One USB3.0, One USB2.0,One USB2.0 OTG
One Micro SD port
One SIM card port
Two uart port compliance with 3.3V voltage level
One Gigabit Ethernet
Two I2C and two SPI
One Mini-PCIe (expandable: PAL / HD-SDI video capture, GPS / Beidou module, AD / DA module,
4G module, storage module, etc.) interface
One FPD-LINK III and one MIPI camera port（Z506-S）
One Mini HDMI 2.0
Size: 109.1mm×77mm ×46mm
Power input: +5V
Temperature: -25℃~+55℃
Weight:406g
