Z506-B Reference Manual V1.0
8
1.2 Ordering Information
Model Options
Functional Description
Z506-B
NANO Fly cloud intelligence box guide cold version, built-in
NANO B01 module, pre-installed Ubuntu 18.04, built-in 16GB
eMMC; 1x USB 3.0,1 x USB 2.0,1 x USB OTG, 1x miniHDMI,
1x GbE, 1x Micro SD, 3x 3.3V UART, 2 x SPI, 2 x I2C, 1x
MiniPCIe, 4G module /mSATA optional; Power indicator light,
power switch button, -20 -- +55℃; Including cable package
(HDMI, serial port, SPI, I2C); Includes power adapter, provides
Ruitai new Era RTSO-6001B Linux4Tegra software support
package, passed THE 3C and CE certification
Z506-S
NANO Fly cloud intelligence box guide cold version, built-in
NANO B01 module, pre-installed Ubuntu 18.04, built-in 16GB
eMMC; 1x USB 3.0,1 x USB 2.0,1 x USB OTG, 1x miniHDMI,
1x GbE, 1x Micro SD, 3x 3.3V UART, 2 x SPI, 2 x
I2C,FPD-Link,1 x MiniPCIe, 4G module /mSATA optional;
Power indicator light, power switch button, -20 -- +55℃;
Including cable package (HDMI, serial port, SPI, I2C); Includes
power adapter, provides Ruitai new Era RTSO-6001B
Linux4Tegra software support package, passed THE 3C and CE
certification
RTS-NANO-AC/DC
Power Adaptor for Z506/-S, 100-240VAC/5V/4A,20W
RTS-IMX390-F120(optional)
FPD-LINK III camera
Cable-RTS-XF120(optional)
Cable for FPD-LINK III camera, length X=2,5,10(m)
RTSV-6911i(optional)
RTSV-6901(optional)
RTSV-6941(optional)
Mini-pcie Video Capture Card,RTSV-6911i (8-channel D1
NTSC/PAL video input), RTSV-6901 (single-channel SDI video
input), RTSV-6941 (single-channel HDMI Video Input)
Order online:
https://shop340963258.taobao.com
https://mall.jd.com/index-824786.html
1.3 Cable Kits and Accessories
Component
Number
Functional Description
microHDMI to HDMI cable
1
Convert Micro HDMI to standard HDMI interface
