RTK REact 100E-045 User Manual

Elektrischer Stellantrieb
Electric actuator
Siłownik elektryczny
REact 60E / 100E- 7020
08/2016
Technische Daten / Technical specification / Dane techniczne
Type / type / typ
REact 60E REact 100E
-030 -045 -090 -170 -030 -045 -090
Regelkraft / operating force / siła w regulacji 6,0 kN 10 kN
Stellweg / stroke / skok max. 60 mm max. 80 mm
Stellgeschwindigkeit / speed / prędkość [mm/s] 0,3 0,45 0,9 1,7 0,3 0,45 0,9
Leistungsaufnahme / power draw / pobór mocy [VA] 27 46 46 81 27 46 81
Motorspannung / motor voltage / napięcie zasilania 24 VDC (BLDC)**, 24 V, 115 V, 230 V, 50/60 Hz*
Isolationsklasse / isolation class / stopień izolacji B
Betriebsart / motor rating standard / standard pracy
S1
100%
S1
100%
S1
100%
S3
50%
S1
100%
S1
100%
S3
50%
Kraftschalter/ force switches / wyłączniki momentowe 2, fest verdrahtet / 2, directly wired / 2, okablowane
Wegschalter / limit switches / wyłączniki krańcowe 2, fest verdrahtet / 2, directly wired / 2, okablowane
Zusätzliche Wegschalter/ additional limit switches/
dodatkowe wyłączniki krańcowe
2, Schaltleistung 4 A, 250 V / rating 4 A, 250 V / obciążalność 4 A, 250 V
Schutzart / protection rating/ stopień ochrony IP 65, DIN EN 60529
Umgebungstemperatur / ambient temperature /
temperatura otoczenia
-20°C...70°C
Einbaulage / mounting position / pozycja montażu
beliebig, jedoch Antrieb nicht nach unten hängend / any, except
upside down / każda poza siłownikiem do dołu
Schmiermittel Getriebe / gear
lubricant / smarowanie przekładni
Divinol Lithogrease, NLGI Klasse / Grade / klasa 0
Kabeleinführung / cable glands / dławiki 4 x M 20
Gewicht / weight / ciężar 6,7 kg
*
Bei 60 Hz erhöht sich die Stellgeschwindigkeit und die Leistungsaufnahme um 20 %
For operation at 60 Hz the speed and power consumption increases by 20 %
Przy sieci 60 Hz prędkość i zużycie energii rośnie o 20%
** Siehe Datenblatt REact 60DC / REact 100DC
** See REact 60DC / REact 100DC Data Sheet
** Patrz karta techniczna REact 60DC / REact 100DC
Zusätzliche Ausstattung / Optional accessories / Akcesoria opcjonalne
Type / type / typ
Potentiometer / potentiometer / potencjometr
Max. 2 1k, 2k 5k Ohm
Stellungsmelder / position indicator / wskaźnik pozycji
REtrans 4W, 3-
Leiter / 3-wire / 3 fils
REtrans 2W, 2-
Leiter / 2-wire / 2 fils
Ausgang / output / wyjście
(0)4...20 mA
0..10 V
Digitale Stellungsregler REpos mit Display / digital positioner
REpos with display / cyfrowy pozycjoner z weświetlaczem
REpos Eingang / Input / wejście
Ausgang / output / wyjście
(0)4..20 mA,(0)2..10
V (0)4..20mA,
(0)2…10V
REpos Profibus DP
REpos mit Bussystem CAN-Open / REpos with bus
system CAN-Open / REpos z CAN-Open
Heizung / heater / grzałka 12-36 V – 3W / 6W, 110-230V - 3 W / 6 W
Prozessregler / process controller / regulator
Qube, 1 Kanal PID Prozessregler / 1-channel PID process controller /
regulator PID 1-kanałowy
