Elektrischer Stellantrieb
Electric actuator
Siłownik elektryczny
REact 60DC / 100DC-7060
07/2016
Maßblatt / dimension sheet / Wymiary
Bild / Rys. 05: Maßblatt/Dimension sheet/wymiary
Elektrischer Anschlussplan / Wiring diagram / Schemat elektryczny
120
Freilassen zum Abheben des Gehäuse-Oberteils
Clearance required for removal of cover
De retirer vierge
60/80 mm Hub/Stroke/Skok
100
34
Ø20
160
4xKabelverschraubung/ dławik
262
M16
177
233
Przestrzeń potrzebna do zdjęcia pokrywy
