PortaMonitorPage 7-10 Switches and menus
CHANNEL Display channel selection for vectorscope mode:
L, R, L+R, L-R
Surround mode (LRCS):
L, R, L+R, L-R, C, S
Surround (LtRt-mode):
Lt, Rt, Lt+Rt, Lt-Rt
SPAN Display range: 15 dB/30 dB/45 dB
GRID Display grid: STD/FINE
PEAKMETER Display PPM: ON/OFF
DISPLAY MEMO Memory (Freeze) ON/OFF
COLOR-BAR <0 Color below 0 dB
-BAR >0 Color above 0 dB
-PEAKHOLD Color for peakhold
7.7.12. Submenu: SURROUND
VECTOR-MODE Surround display preset:
L and R - inclination of axis:
13° or 25°
3 - 1 mode: 13 deg or 25 deg L, C, R, S
3 - 0 mode: 13 deg or 25 deg L, C, R
2 - 1 mode: 13 deg or 25 deg L, R, S
AGC Mode of operation for gain ranging: FAST/SLOW
HOLD Vectorscope refresh rate: FAST/MEDIUM/SLOW
PPM-POSITION PPM arrangement: L.R.C.S./L.C.R.S./L.C.S.R.
CORR [L/R] Correlator display for L and R: ON/OFF
COLOR-VECTOR Color for vectorscope
-GRID Color for vectorscope grid
Mode Lt/Rt
LtRt-Source Source definition for LtRt signal:
INT.-MATH: internal math for calculating LtRt from
the discrete input signals
ALT.-INPUT: Display of an external processed LtRt
signal. Input via channel 1/2 of the alternate domain
(alternate to LCRS domain)
LtRt-MATH LtRt calculation factor for internal math:
SURR 0,707
SURR 0,5
SURR off
PPM-MODE Mode of operation for PPM
SURR.4CHA: Display of all four surround input
channels with four PPM´s.
SURR.LtRt Display of the two-channel LtRt signal
(no digial error-function)
GONIO-KEY Defines GONIO key function:
SURR <> LtRt toggle function vectorscope and LtRt
SURROUND: surround display only, no Lt/Rt display
selection
