Ruijie Reyee RG-NBR-E Series

Cookbook Upgrade and Maintenance
134
Figure 4-4 Console port on the device
 Console cable
○ Type 1: One end of the cable is a 9-pin COM port, and the other end is an RJ45 connector.
○ Type 2: One end of the cable is an RJ45 connector, and the other end is a USB connector.
