Cookbook Overview
11
They are USB2.0 ports that connect to USB-compliant peripheral devices,
such as USB flash drives.
If it is steady orange, the port is connected at a rate of 1000 Mbit/s.
If it is off, the port is connected at a rate of 10 Mbit/s or 100 Mbit/s.
If it is steady green, the port is connected at a rate of 10 Mbit/s, 100
Mbit/s, or 1000 Mbit/s.
If it blinks green, the port is receiving or transmitting traffic.
If it is steady green, the port is connected.
If it blinks green, the port is receiving or transmitting traffic.
A WAN port by default and supports the WAN/LAN switchover.
Supports 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-LX20/LH40-
BIDI SPF modules.
An SFP+ port by default and supports XG-SFP-SR-MM850, XG-SFP-
LR-SM1310 and XG-SFP-ER-SM1550 modules and BIDI modules.
Can be configured as an SFP port and supports 1000BASE-SX/LX/ZX
mini GBIC and GE-SFP-LX20/LH40-BIDI SPF modules.
A LAN port by default and supports the WAN/LAN switchover.
Eight 10/100/1000M self-adaptive fast Ethernet ports (copper ports 0-7 )
that support automatic recognition of network cables and cross-over cables:
LAN0 (GE 0/0) is a LAN port and WAN0 (GE 0/7) is a WAN port, and
they do not support the WAN/LAN switchover.
By default, LAN6/WAN1 (GE 0/6) is a WAN port and supports the
WAN/LAN switchover.
By default, LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2), LAN3/WAN4
(GE 0/3), LAN4/WAN3 (GE 0/4) and LAN5/WAN2 (GE 0/5) are LAN
ports and support the WAN/LAN switchover.
In bridge mode, LAN0 (GE 0/0) port is also the MGMT port.
Restarts the router. Press and hold this button for more than 5 s to reset the
router to factory defaults.
If it blinks green, the system is being initialized.
If it is steady green, system initialization is completed.
If it is steady red, the system is in abnormal state.
