Ruijie Reyee RG-NBR-E Series User Manual

Cookbook Overview
12
Figure 1-8 Back Panel of Ruijie RG-NBR6215-E Router
Table 1-11 Description of the Back Panel of Ruijie RG-NBR6215-E Router
No.
Indicator/Port
Description
1
Retainer holder
Holds the power cord retainer to secure the power cord.
2
Power port
Connects to an AC power cord.
3
Power switch
Controls power supply.
4
Grounding screw
Connects to the grounding system of the installation site through the
grounding wire to provide grounding protection.
5
Hard Disk expansion
card slot
Fits the hard disk module. The supported hard disk module model is
RG-NBR-HDD-1T.
2. Specifications of Ruijie RG-NBR6215-E Router
Table 1-12 Specifications of Ruijie RG-NBR6215-E Router
Item
Description
Model
RG-NBR6215-E
Storage
DDR4 SDRAM: 2 GB
BOOTROM: 8 MB
eMMC: 8 GB
SATA: 1 TB (OPTIONAL)
2 3
5 4
1
