Ruijie Reyee RG-NBR-E Series User Manual

Cookbook Overview
13
Item
Description
I/O setup
Eight 10/100/1000M self-adaptive fast Ethernet ports that support automatic
recognition of network cables and cross-over cables:
○ By default, LAN0 (GE 0/0), LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2),
LAN3/WAN4 (GE 0/3), LAN4/WAN3 (GE 0/4) and LAN5/WAN2 (GE 0/5)
are LAN ports, while WAN0 and LAN6/WAN1 (GE 0/6) are WAN ports.
○ LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2), LAN3/WAN4 (GE 0/3),
LAN4/WAN3 (GE 0/4), LAN5/WAN2 (GE 0/5) and LAN6/WAN1 (GE 0/6)
support the WAN/LAN switchover.
One SFP+/SFP port:
○ An SFP+ port by default and supports XG-SFP-SR-MM850, XG-SFP-LR-
SM1310 and XG-SFP-ER-SM1550 modules and BIDI modules.
○ Can be configured as an SFP port and supports 1000BASE-SX/LX/ZX mini
GBIC and GE-SFP-LX20/LH40-BIDI SPF modules.
○ A LAN port by default and supports the WAN/LAN switchover.
One SFP port:
○ Supports 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-LX20/LH40-BIDI
SPF modules.
○ A WAN port by default and supports the WAN/LAN switchover.
One management port (in bridge mode)
One console port
Two USB ports
Hardware disk module
One hardware disk module (optional)
Hot swapping
Not supported
Interface standard
Ethernet: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX,
10GBASE-SR/LR/ZR
Console port: RS-232
Dimension (W x H x D)
440 mm x 43.6 mm x 200 mm(excluding the foot pad)
Voltage
100-240 V; 50/60 Hz
Power
Less than 25 W
Working environment
Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
Note
Not all USB disks are supported. The Kingston USB disk with FAT 32 is recommended.
Caution
 Avoid vibration and collision during device moving and usage when the device has the hard disk module
installed.
