Ruijie Reyee RG-RAP6260 User Manual

·
LED
One LED (blue)
Power Supply
PoE: IEEE 802.3at (PoE+)
Warning：802.3af or non-standard POE adapter may cause unknown issues. Please use Ruijie
POE+ switch
Power Consumption
Maximum: 17W
Temperature
Operating: -40℃ to 65℃ (-40℉ to 149℉)
Storage: -40℃ to 85℃ (-40℉ to 185℉)
Humidity
Operating: 0% to 100% (non-condensing)
Storage: 0% to 100% (non-condensing/condensing)
Installation
Wall/Pole mount
Safety Standards
GB4943
IEC 60950-1
EMC Standards
GB9254
EN301 489
EN50155
EN50121
Vibration Standards
IEC61373
Radio
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
MTBF
>400,000H
The weight refers to the weight of host and bracket.
1.2 Product Image
The RG-RAP6260(G) provides one 10/100/1000Base-T Ethernet port (Support PoE) and one 1000Base-X SFP port
(optional).
Figure 1-1 Appearance of RG-RAP6260(G)

Ruijie Reyee RG-RAP6260 Specifications

General

Brand	Ruijie
Model	Reyee RG-RAP6260
Category	Wireless Access Point
Language	English
