How to Assemble the Manual Pump Diaphragm Kit
Place the "U" shape slot of the Handle
onto the recess of the Adjusting Valve
Stem.
There are 2 recesses on the Adjusting
Valve Stem. The upper recess replicates
the Swift Expression setting, and the
bottom recess replicates the Natural
Expression setting.
Push the Handle down onto the hinge
of the Cup until it "snaps" into place.
"U" shape slot
3-1
3-3
4
Hinge
Rumble Tu Manual Pump Assembly Rumble Tu Manual Pump Assembly
3-2
Swift Expression
Natural Expression
To Next Page
