Runva EWP3500 - Winch Parts List Ewp2500;Ewp3500

13
WINCH PARTS LIST （EWP2500/EWP3500）
No.
Part #
Qty
Description
Remark
1
P0250100-D
1
Motor Assembly（Used in EWP2500）
Used in D and A type winch
P0250100-U
Used in U type winch
P0350100-D
1
Motor Assembly（Used in EWP3500）
Used in D and A type winch
P0350100-U
Used in U type winch
2
P0250001
4
Cap Screw M8 x 16
3
P0250002
1
Transition Shaft
4
P0250003
2
Tie Bar
5
P0250004
1
Hexagonal Shaft
6
P0250005
1
Front Bush Drum
7
P0250006
6
Thick Flat Washer Φ6
8
P0250007
6
Locking Washer Φ6
9
P0250008
1
Screw M6 x 8
10
P0250009
2
Cap Screw M6 x 70
11
P0250010
1
Drum
12
P0250011
1
Rear Bush Drum
13
P0250012
1
Front Thrust Washer
14
P0250013
1
Gear Ring Output
15
P0250200
1
Gear Carrier Assembly
16
P0250014
1
Gear Ring
17
P0250015
1
Gear Housing / End Bearing
18
P0250016
1
Bearing Holder
19
P0250017
1
Roller Bearing
20
P0250018
1
Clutch axes
21
P0250019
1
Cam Clutch Gear
22
P0250020
1
Spring
23
P0250021
1
Cover Clutch Housing
24
P0250022
1
Nylon Bearing
25
P0250023
1
Elastic Collar
26
P0250024
1
Clutch Handle
27
P0250025
1
Locking Washer Φ5
28
P0250026
1
Cap Screw M5 x 12
29
P0250027
4
Cap Screw M6 x 25
30
P0250028
4
Hex Flange Nut M8
31
P0250029
4
Locking Washer Φ8
32
P0250030
4
Thick Flat Washer Φ8
33
P0250300
1
Roller Fairlead
34
P0250031
1
Mounting Channel
35
P0250032
2
Cap Screw M8 x 20
36
P0250033
2
Cap Screw M8 x35
37
P0250034
2
Terminal Protector
38
P0250400
1
Cable Assembly
Used in EWP2500
P0350400
Used in EWP3500
39
P0250035
1
Strap
40
P0250500
1
Control Section Of D Type Winch
By choice,Used in EWP2500
P0350500
By choice,Used in EWP3500
41
P0250600
1
Control Section Of A Type Winch
By choice,Used in EWP2500
P0350600
By choice,Used in EWP3500
42
P0250700
1
Control Section Of U Type Winch
By choice,Used in EWP2500
P0350700
By choice,Used in EWP3500
43
P0250036
1
Ring Seals
44
P0250037
1
“O” Ring Seals
45
P0250038
1
“O” Ring Seals
