MODEL：F67Q/F71Q/F68Q/F69Q/F116Q/F117Q
34
Filter
Material
Filtering
Flow Rate
Backwash
Flow Rate
Filtering
Flow Rate
Backwash
Flow Rate
mm L m
3
/h m
3
/h m
3
/h m
3
/h
φ180×1130 16 0.3 0.9 0.6 1.3
φ205×1300 25 0.4 1.1 0.8 1.7
φ255×1390 40 0.6 1.7 1.2 2.6
φ300×1390 60 0.8 2.5 1.7 3.8
φ355×1670 100 1.2 3.4 2.4 5.2
φ400×1670 120 1.5 4.5 3.1 6.8
Attention: the filtering flow rate of carbon filter is calculated based on the
12m/h operation rate; the backwash flow rate is calculated based on the
10L/(m
2
*s) backwash intensity; the filtering flow rate of sand filter is
calculated based on the 25m/h operation rate; the backwash flow rate is
calculated based on the 15L/(m
2
*s) backwash intensity.
Commonly used tank size, resin volume, brine tank and and injector
configuration for softener system
F116Q, F117Q：
Tank Size
(mm)
Resin
Volume
(L)
Flow
Rate
(t/h)
Brine Tank
Size
(mm)
The Minimum Salt
Consumption for
Regeneration(Kg)
Injector
Model
Control
Valve
Model
φ180×1130
16
0.5
φ250×520
2.40
6303
F117Q
φ205×1300
25
0.7
φ390×810
4.00
φ255×1390
40
1.2
φ390×810
6.00
6304
φ300×1650
60
1.8
φ450×940
9.00
6307
φ355×1650
100
2.5
φ500×1060
15.00
φ255×1390
40
1.2
φ390×810
6.00
6306
F116Q
φ300×1650
60
1.8
φ450×940
9.00
φ355×1650
100
2.5
φ500×1060
15.00
6308
φ400×1650
120
3.5
φ550×1160
18.00
6309
φ450×1650
150
4.5
φ550×1160
22.50
F68Q, F69Q：
