Runxin F79A-LCD User Manual

MODEL 82602-F79A-LCD/82602B-F79B-LCD/82604-F82A-LCD/82604B-F82B-LCD
13
while it is in Backwash status, it will end backwash and go to Brine
&Slow Rinse at once.)
 Press in program display mode, and it will return in Service; press
in program set mode, and it will return program display mode.
 Press while adjusting the value, then it will return program display
mode directly without saving value.
② Down▼ and Up ▲
 In program display mode, press ▲ or ▼ to view all values.
 In program set mode, press ▲ or ▼ to adjust values.
 Press and hold both ▲ and ▼ for 5 seconds to unlock the buttons.

Runxin F79A-LCD Specifications

General

Model	F79A-LCD
Category	Control Unit
Display Type	LCD
Water Quality Monitoring	Yes
Max. Water Production Capacity	4m³/h
Power Supply	AC 100-240V, 50/60Hz
Water Temperature	5-50°C
Drain	1/2"
Water Pressure	0.15-0.6 MPa
Transformer Input	AC 100-240V, 50/60Hz
Brine Line Connector	3/8"
Riser Pipe	1.05 inch OD
