Runxin N77A3 User Manual

MODEL: 63518-N77A1 /63618-N77A3/ 53518-N77B1
7
B. Technical parameter
Transformer Output: DC24V/1.5A
Model
Connector Size
Flow
Rate m
3
/h
@0.3MPa
Remark
Inlet/
Outlet
Drain
Outlet
Brine Line
Connector
Base
Riser
Pipe
N77A1
2″M
1.5″M
3/4″M
4-8UN
1.5″OD
(50mm)
18
DF softener，
by day
N77A2
DF softener,
by hour
N77A3
DF softener，
meter type
N77B1
2″M
1.5″M
3/4″M
4-8UN
1.5″OD
(50mm)
18
DF filter，by
day
N77B2
DF filter, by
hour
Remark: M—Male F—Female OD—Outer Diameters,
1.05OD=26.7 mm
1.5. Installation
A. Installation notice
Before installation, read all those instructions completely. Then
obtain all materials and tools needed for installation.
The installation of product, pipes and circuits, should be
accomplished by professional to ensure the product can operate
normally.
Perform installation according to the relative pipeline regulations
and the specification of Water Inlet, Water Outlet, Drain Outlet, and Brine
Line Connector.
B. Device location
① The filter or softener should be located close to drain.
② Ensure the unit is installed in enough space for operating and
maintenance.

Runxin N77A3 Specifications

General

Brand	Runxin
Model	N77A3
Category	Control Unit
Language	English
