Runxin N77B1 User Manual

MODEL: 63518-N77A1 /63618-N77A3/ 53518-N77B1
45
N77A1/N77A3 Valve Body Components (Item No. 9, 36 only for N77A3)
Item
No.
Description
Part No.
Quantity
Item
No.
Description
Part No.
Quantity
1
Side-mounted
Connector
5458002
1
31
Three-core Spring
5517001
1
2
Screw, Cross
ST3.9X13
8909003
5
32
Control Board
6382030
1
3
Connector
8458018
1
33
Wire for Locating
Board
5511006
1
4
O-ring 104.6
X5.7
8378146
1
5
O-ring 48.9
X2.62
8378071
1
34
Front Cover
8300012
1
6
Seal Ring
8371008
1
35
Toggle
8126004
2
7
Brine Line Flow
Control
8468012
1
36
Probe wire
6386003
1
8
Animated
Connector
8947005
1
37
Wire for power
5513001
1
9
Flow meter
5447003
1
38
Locking Ring
8994009
2
10
Screw, Cross
ST2.9X9.5
8909008
14
39
Small Gear
5241008
2
11
Screw, Cross
ST3.9X19
8909016
8
40
Button C4X12
8971001
2
12
Wire for power
8370044
1
41
Motor
6158036
2
13
Fixed Disk
8469022
1
42
Shaft
8258012
1
14
Moving Disk
8459024
1
43
Fixed Disk
8459023
1
15
Shaft
8258005
1
44
Moving Disk
8469021
1
16
Anti-friction
Washer
8216006
2
45
Wire for power
8370042
1
17
O-ring 59.92
X3.53
8378110
4
46
Hexagonal Nut
8940002
5
18
O-ring 107.54
X3.53
8378112
4
47
Cable clip
8126002
2
19
Pressure Nut
8092009
2
48
Junction Plate
8152009
1
20
Locating board
6380017
1
49
Pin 2.5X12
8993004
2
21
Gear
5241007
2
50
Injector
5468019
1
22
Screw, Cross
ST4.8X19
8909018
2
51
O-ring 52X3
8378096
1
23
Dust Cover
8005011
1
52
Injector Cover
8315007
1
24
Board Back
Cover
8315008
1
53
Screw, Cross
ST4.8X25
8909021
4
25
Screw, Cross
ST2.2X6.5
8909004
8
54
Screw, Cross
M4X20
8902007
2
26
Display Board
6381007
1
55
3/4” Ball Valve
2976008
1
27
Cable clip
8126001
1
56
Display Shelf
8040003
1
28
Board Front
Cover
8300013
1
57
Valve
Body(ABS+GF10)
8022057
1
29
Sticker
8865011
1
Valve
8022139
