You may cut the strip if you wish one time only in a multiple of 3 LEDs. Please cut the strip within the copper as per below.
Note: Do not cut strip while connected to power source. Do not let end of cut strip touch frame of bike. Seal the cut end of the
strip with the supplied silicone sealant. Cut ends of strips that are not sealed will cause a negative short resulting in the lights
coming on very dim which could burn the circuits of the remote-control module.
Your warranty and guarantee are VOID if the cut end of the strip is not sealed.
Install the Engine Kit
We recommend starting with the 36-LED strips. These strips should be installed to the bottom of the right side, and the bottom of
the left side of the fuel tank shining down on the engine headers. One of the 9-LED strips should be installed behind the breather
between the engine headers shining towards the other side, another one behind the horn between the engine headers shining
towards the other side, and the remaining (10) 9-LED strips can be placed anywhere under the gas tank to shine downwards. Clean
the mounting surface with the supplied alcohol towels first. Once the alcohol dries, use the supplied 3M adhesion promoter to
prepare the surface where you’ll be attaching the strips. The 3M adhesion promoter is used to enhance the adhesion strength of the
3M tape on the back of the light strips and makes a permanent bond. YOU CANNOT SKIP THIS STEP. Always apply 3M Promoter to
any surface LED strips will be mounted. Note - Do not get the promoter on your hands. Let the promoter dry before proceeding.
We suggest you position the LED strip before removing the tape backing. When ready, remove a small amount of tape backing from
one end of the strip while holding it in position. Continue to peel it off and press as you go to ensure the tape doesn’t stick
prematurely to the wrong place.DO NOT put excess pressure on the resistors or on the LEDs when mounting them down. Always try
to connect 2 strips together with a “Y-Connector”, then the “Y-Connector” to an 18” or 36” extension wire whenever possible then
connect the extension wire(s) to the Remote-Control Box.
The promoter used will cause immediate and permanent adhesion on contact with the 3M tape so be sure to TAKE YOUR TIME.
You must get it right the first time for a guaranteed trouble-free installation.
For best results, attach your lights within one hour or less after the promoter has been applied.
Install the Road Coverage Kit
We recommend installing these 36-LED strips on the bottom of the frame at a 45-degree angle on the left and right sides to shine
down on the highway. They must be at a 45-degree angle and not directly on the bottom at a 90-degree angle. This is to avoid
damage to the strips if your bike is put on a lift. Clean the mounting surface with the supplied alcohol towels first. Once the alcohol
dries, use the supplied 3M adhesion promoter to prepare the surface where you’ll be attaching the strips. The 3M adhesion
promoter is used to enhance the adhesion strength of the 3M tape on the back of the light strips and makes a permanent bond. YOU
CANNOT SKIP THIS STEP. Always apply 3M Promoter to any surface LED strips will be mounted. Note - Do not get the promoter on
your hands. Let the promoter dry before proceeding.
We suggest you position the LED strip before removing the tape backing. When ready, remove a small amount of tape backing from
one end of the strip while holding it in position. Continue to peel it off and press as you go to ensure the tape doesn’t stick
prematurely to the wrong place.DO NOT put excess pressure on the resistors or on the LEDs when mounting them down. Always try
to connect 2 strips together with a “Y-Connector”, then the “Y-Connector” to an 18” or 36” extension wire whenever possible then
connect the extension wire(s) to the Remote-Control Box.
