Installation
With the door appliance closed and the appliance situated in the aperture, you will
need to:
Measurement A – Measure from the underside of the kitchen unit to the bottom
of the bottom of the fixing bracket.
Measurement B - measure from the underside of the kitchen unit to the top of a
kitchen cabinet door on a adjacent kitchen unit/door
Remove the 2 screws that fix the fixing bracket to the appliance door and carefully
remove the fixing bracket.
On the back of the cabinet door (the side that will not be seen) mark a vertical
centre line approximately 15cm from the top of the door.
14
Back of the cabinet door
A
B
