6
ENG
ASSEMBLY INSTRUCTION
A. Attach the lower steel poles (1) to the legs of the trampoline using the brackets
and the spacers. The spacer must be placed between the safety net’s lower steel
poles and the trampoline’s legs. Insert a bracket and spacer at the lower part
of the leg and at the upper part, just below the mat’s ring. Tighten them in the
correct position using the wing nuts and then put the safety caps on top.
B. Insert the upper steel poles (2) into the lower steel poles (1) and put the plastic
caps (7) on top of the poles.
C. Unfurl the safety net and
hangit up in the steel poles.
This is what you need to do:
• Put the net inside the steel
poles as shown in the
picture (C1).
Start with the
opening on the right
Opening with a D ring
and a plastic hook
1
1
B
A
C1
