Reaction Maximum possible
Masking value
Reaction Maximum possible
Masking value
1 6 5 4
2 6 6 4
3 6 7 3
4 5 8 2
Setting Adjustment range
Th Level 0 – 100
Th Tone 60 – 500
Th Sens 0 – 30
VCO Yes, No
Th SAT 0 – 20
Audio Gain 0 – 60
Volume 1 – 30
Iron volume 0 – 30
Tones Coin 1, 2, 3; Relics 1, 2, 3; User 1, 2, 3
Wireless Off, Ch 1, Ch2
The Audio page contains the following settings:
Th Level
The Threshold is the background sound which is always heard while the detector is
active. It can be increased or decreased depending on the user’s preferences and the level of
noise at the search site. The level of the Threshold should be set so that it is only slightly
audible – in this way you can be sure that you will hear even the quietest signals from objects.
The Threshold is very important – it enables the All metal channel to be correctly reset by the
user. Th Level and Th Tone adjustments can be made in the Menu at the same time as listening
to the effects of these changes.
Th Tone
The Th Tone should be set as you wish – each user will have their own preferences as to
the sound frequency which is the most appropriate.
Th Sens
The Th Sens regulates the level of the Threshold from the All metal channel. This allows
the operation mode to be modified. When a Th Sens setting of 0 is used the detector becomes
dynamic, but for higher levels the influence of the All metal channel on the level of the Threshold
is also higher. For Th Sens settings above 0 (if an Audio Gain is also set above 0), the detector
switches to Dual mode.
RUTUS Alter71 ver. 2.0 14
