29
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
MATAWAY
FIGURE 1
CHASSIS
1 64006-03 WASHER, 3/8 HELICAL LCK 2
2 64123-82 BOLT-HEX 3/8-16X2-1/2 1
3 64123-107 BLT-HEX 5/16-18X7/8 2
4 64163-55 WASHER .328X.75X14 GA 12
5 64164-19 KEY WOODRUFF.19X.75 #9 3
6 64001-2 NUT-JAM 3/8-16 4
7 64123-50 BOLT-HEX 3/8-16X1 2
8 64123-54 BLT-HEX 5/16-18X3/4 11
9 64268-03 NUT-3/8-16 HEX 1
10 64197-001 BLT-TDFM 5/16-18X3/4 4
11 64018-9 BLT-CRG 5/16-18X3/4 G5 4
12 64268-02 NUT-FL NYLN LCK 5/16-18 2
13 64140-1 COTTER PIN 4
14 841261 SPROCKET, 16T 1/2P BLK 1
15 516825.7 GUARD 1
16 516944 HUB 2
17 517226 BRG,SLV .33 .50 .20 IRON 2
18 517348 SPROCKET 1
19 517641 SCRW,SPCL.38-16 1.75 HX 1
20 518506 SPRING 2
21 519038 BUSHING 2
22 4163618.7 LEVER 2
23 519040 HOOK, UPPER RIGHT 1
24 519041 HOOK, UPPER LEFT 1
25 519042 NUT 2
26 4130674 CLAMP, ROD LOWER 2
27 4163522.7 CLAMP, REEL 2
28 4163619.7 PLATE 1
29 519059 SHAFT,FRONT 1
30 519874 RACE,INNER 1
31 4163635.7 SCRAPER, WHEEL 2
32 4163630.7 LINK, LIFT 4
33 4163602.7 STOP, BELT 1
34 548962 HOUSING,BEARING 4
35 521856 BEARING,BALL 2
36 521857 COLLAR,BRG LOCKING 2
37 540195 FRAME 1
38 85010N FITTING,GREASE 1/4 SPC 4
39 4163614.7 ARM, LEFT 1
40 4163613.7 ARM, RIGHT 1
41 4124194 WHEEL, 4.10/3.50-4 2PLY 2
INCLUDES ITEMS 42-47)
42 64025-03 NUT-HEX 5/16-24 4
43 64006-02 LOCKWSHR-HELICAL 5/16 15
44 306861 SCRW,.31-24.625 YS HX 4
45 548123 BEARING, WHEEL 2
46 548543 TIRE-4.10/3.50-4, 2 PLY 1
47 548546 TUBE 1
48 4124196 WHEEL ASSY 2
(INCLUDES ITEMS 42-44, 47, 49 & 50)
49 517332 RIM 1
50 523264 TIRE 1
51 64141-6 NUT, 5/16-18 4
52 64144-02 SNAP RING 3/4 2
53 29-045 GREASE FTG 1/4-28 45DEG 1
54 64151-18 NUT, HEX 2
55 4163603.7 WEIGHT AY 1
56 4163735 CHAIN,#40 ROLLER 1
57 521845 BEARING,NEEDLE 1
58 4113841 CONNECTOR LINK #40 NP 1
59 64163-61 WSHR .81X.406X16GA 5
60 644044-18 SCREW-SET 5/16-18 x 5/16 6
61 64144-03 SNAP RING 7/8" 2
62 64188-36 PIN CLEVIS 7/16X1-1/4 4
63 64123-68 BLT-HEX 5/16-18X1 2
64 64141-4 NUT-WLF 3/8-16 2
65 64123-87 BOLT-HEX 3/8-16X1-3/4 2
66 4161123 LABEL-RYAN OVAL LARGE 1
67 524544 DECAL,REEL HEIGHT ADJ. 1
68 4163696 DECAL,DANGER 1
69 4163592 LABEL-BELTS/SERVICE 1
70 64229-02 NUT-NYLOC 5/16-18 2
71 64168-2 COTTER-HAIRPIN .08x1.19 2
72 64163-31 WSHR-25-64X1X12 4
73 340830 DECAL-CAUTION, SPANISH 1
