RYOBI 12 in. DRILL PRESS – MODEL NUMBER DP121L
4
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your DRILL PRESS or when ordering repair parts.
PARTS LIST FOR FIGURE A
75 089140300049 SCREW (SET W/DOG POINT
M8 X 16 mm HEX SOC.) .....1
76 089140300050 RACK ..................................1
77 089140200067 SCREW
(M4 X 8 mm PAN HD.) .........4
78 089140300052 SENSOR SEAT .................... 1
79 089140200031 RUBBER GROMMET ..........2
80 13202014A CORD CLAMP W/SLEEVE ..2
81 089140300053 GEMEL SEAT ......................2
82 089140300054 MOTOR PULLEY-LOWER ..1
83 089140300055 MOTOR PULLEY-UPPER ...1
84 089140300056 RETAINING RING (14) .........1
85 089140300057 SCREW
(M4.2 X 9.5 mm PAN HD.) ...4
86 089140300058 GEMEL CLAMP ..................2
87 089140300059 GEMEL ................................ 1
88 089140300060 SCREW
(M8 X 25 mm HEX SOC.) ....4
89 TDP11001 LOCK WASHER (M8) ..........4
90 089140300062 WASHER (M8) .....................4
91 089140300063 MOTOR PULLEY SPRING ..1
92 089140300064 HOOD SPRING ...................1
93 089140300065 PALLET SPRING .................1
94 089140300066 KEY (M4 X 75 mm) .............. 1
95 089140300088 MOTOR ...............................1
96 089140300068 ROLL PIN (D6 X 16 mm) .....1
97 089140300069 HEAD STOCK .....................1
98 089140200087 SCREW (M4.2 X 13 mm
COUNTERSUNK HD.) ......... 2
99 089140300070 GEAR SHAFT ......................1
100 089140200074 SHAFT SEAT .......................1
101 089140200075 RETAINING RING (16) .........1
102 089140200076 DEPTH STOP RING ............1
103 089140200084 ROD ....................................3
104 089140200086 KNOB DEPTH SCREW .......1
105 089140200085 HUB ....................................1
106 089140300071 ROLL PIN (D2.5 X 12 mm) ..1
107 089140200088 BULB SOCKET W/NUT ......1
108 089140200089 BULB SOCKET-BRACKET .. 1
109 089140300083 SCREW
(M4 X 12 mm PAN HD.) .......2
110 089140300072 SCREW
(M8 X 16 mm HEX SOC.) ....1
111 089140300073 WASHER (M8) .....................1
112 089140300074 SPRING ...............................1
113 089140200032 LASER LIGHT .....................2
114 089140200030 ROLL PIN (D2.5 X 16 mm) ..1
115 TDP08001 EXT. TOOTH LOCK WASHER
(M5) .....................................2
116 089140300076 LED ASSEMBLY ..................1
117 089140300077 BAFFLE ...............................1
118 13202021 SPECIAL SET SCREW ........ 1
119 TDP03002 HEX SCREW (M8 X 8 mm) .. 1
120 089140300901 SCALE LABEL
(FOR BRACKET) .................1
121 089140300078 SCREW
(M5 X 8 mm PAN HD.) .........2
122 13406002A TABLE INDICATOR ..............1
123 089140200903 DEPTH (STROKE) INDICATOR . 1
124 089140200905 LASER WARNING LABEL-1 .. 1
125 089140300903 WARNING LABEL ...............1
126 089140300904 DATA LABEL .......................1
127 089140300905 SPEED ADJUST LABEL ...... 1
128 089140200908 LOGO LABEL ...................... 1
129 089140200909 LAMP WATT LABEL ........... 1
130 089140300907 DEPTH SCALE LABEL ........ 1
131 089140200911 LASER WARING LABEL-2 ..1
132 984406003 SWITCH KEY ......................1
133 089140200092 VISE (2.5 in.) ........................ 1
134 089140200102 WASHER .............................3
135 089140200912 LASER LABEL ..................... 1
136 089140300081 HEX NUT (M10 mm) ............1
137 089140300082 CAPACITOR
(MOTOR) DP121L ...............1
138 089140300084 CABLE CLAMP ...................1
139 089140300085 INSULATING TAPE ..............1
140 089140300086 WASHER .............................1
141 089140300087 MOTOR CUSHION..............1
983000642 OPERATOR’S MANUAL
12-7-12
(REV:08)
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
