Ryobi DS1100 - Parts List

Page 11
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
DETAIL SANDER or when ordering repair parts.
RYOBI DETAIL SANDER – MODEL NUMBER DS1100
1 Data Plate.................................................................................. 1
2 Screw (#6-19 x 5/8 in. Pan Hd.) .............................................. 12
3 Housing Assembly..................................................................... 1
4 Switch Assembly (Includes Key No. 5)...................................... 1
5 Switch Cover ............................................................................. 1
6 Spherical Ring ........................................................................... 1
7 Arm Support .............................................................................. 1
8 Sleeve Bearing .......................................................................... 1
9 Motor Assembly (Includes Key No. 8) ....................................... 1
10 Black Lead................................................................................. 1
11 Arm Cover ................................................................................. 1
12 Cord Assembly .......................................................................... 1
13 Logo Plate ................................................................................. 1
14 Arm............................................................................................ 1
15 Dowel Pin .................................................................................. 1
16 Sandpaper................................................................................. 1
17 Foot w/Pad ................................................................................ 1
18 Screw (#4-24 x 3/8 in. Pan Hd.) ................................................ 1
19 Foot Cover................................................................................. 1
20 Cap Screw (#8-32 x 7/16 in. Hex Socket) ................................. 1
21 Rubber Washer ......................................................................... 1
Owner’s Manual
Key
No. Description Quan.
Key
No. Description Quan.
PARTS LIST
WARNING:
IMPROPER REPAIR OF A DOUBLE INSULATED TOOL CAN RESULT IN DAMAGES TO THE DOUBLE INSULATION SYSTEM POSSIBLY
CAUSING ELECTRICAL SHOCK OR ELECTROCUTION. ANY REPAIRS REQUIRING DISASSEMBLY OF YOUR TOOL REQUIRES SAFETY
TESTING AND SHOULD ONLY BE PERFORMED BY A FACTORY SERVICE CENTER OR OTHER QUALIFIED SERVICE ORGANIZATION.
