ADJUSTING THE ROTATING HANDLE POSITION
See gure 3.
1. Turn off the tool.
2. Press and hold the handle lock button, then turn the
rotating handle to the desired position until it snaps
in place.
WARNING
Do not adjust the rotating handle while the tool is in
operation.
THREE-POSITION AUXILIARY HANDLE
See gure 5.
Speci cally designed and angled to three-position for
maximum comfort and control.
MOUNTING THE GRINDING WHEEL
See gure 4 - 6.
WARNING
Check carefully whether or not there are cracks in the
wheel. Replace a cracked wheel immediately.
Attach the disc flange, the grinding wheel and the
clamp nut to the spindle shaft.
Be sure the disc flange is properly seated on the
spindle shaft.
Depress the lock button located on the right side of
gear case.
Using the wrench provided, tighten the clamp nut in a
clockwise direction.
TOOL-LESS WHEEL GUARD
See gure 7 - 8.
Release the wheel guard lock lever then turn the tool-less
wheel guard to the desired position. The maximum turning
angle is 90° on either side; otherwise the guard cannot
be locked.
LIVE TOOL INDICATOR
This tool features a live tool indicator which illuminates as
soon as the tool is connected to the supply. This warns the
user that the tool is connected and will operate when the
switch is pressed.
MAINTENANCE
After use, check the tool to make sure that it is in good
condition.
It is recommended that you take this tool to a Ryobi
authorized service center for a through cleaning and
lubrication at least once a year.
WARNING
Do not make any adjustments while the motor is in
motion.
Always disconnect the power cord from the socket
before changing removable or expendable parts
(grinding disc, cutting disc etc.), before lubricating or
working on the unit.
WARNING
To ensure safety and reliability, all repairs should be
performed by an authorized service center or other
quali ed service organization.
