13. Livetool Indicator
TM
THANK YOU FOR BUYING A RYOBI PRODUCT
INSTRUCTIONS FOR SAFE HANDLING
Never use the tool if its cover or any bolts or screws are missing. If the cover, bolts
or screws have been removed, replace them prior to use. Maintain all parts in good
working order.
Always secure tools when working in elevated positions.
Never touch the grinding wheel or other moving parts during use.
Never start a tool when its rotating component is in contact with the work piece.
Never lay a tool down before its moving parts have come to a complete stop.
present a hazard.
REPLACEMENT PARTS : When servicing use only identical replacement parts.
Do not use wheels having a maximum permissable speed below 6600 rpm.
ANGLE GRINDER SAFETY PRECAUTIONS
DESCRIPTION
the product.
To e
nsure your safety and satisfaction, carefully read through this
OWNERʼS MANUAL and the SAFETY INSTRUCTIONS before using
5. ON/OFF switch
1. Grinding wheel
2. Tool-
less wheel guard
3. Aux. handle
4.
Rotary handle lock button
10.Wrench
6.
Safety lock
7.
Disc flange
8.
Clamp nut
9.
11. Spindle lock button
Check that the speed marked on the grinding wheel is equal to or
greater than the rated speed of the tool.
Ensure that the d
imensions of the grinding wheel are compatible
with the tool and that the wheel fits the spindle.
Grinding wheels must be stored in a dry place.
Do not
store objects on top of the grinding wheel.
Grinding wheels must not be used for any operation other than grinding.
Grinding wheels must be stored and handled with care in accordance
with the manufacturer's instruction.
Inspect the grinding wheel before use to ensure that it is not chipped
or cracked. Chips or cracks can cause the wheels to shatter, resulting
in possible serious injury.
4
12.Wheel guard lock
Grinding wheel
Frequency
Voltage*
Input
S
pindle thread
No load speed
Disc bore size
Net weight
The use of accessories or other than those recommended in this manual might
Ensure that the wheel is fitted in accordance with this manual.
Ensure that the g
rinding wheel is correctly mounted and tightened
before use and run the tool at n
o-load speed for 30 seconds in a
safe position. Stop immediately if there is considerable vibration or if
other defects are detected. If this condition occurs, check the tool to
determine the cause.
Do not use s
eparate reducing bushings or adapters to adapt large
hole grinding wheels.
Check that the work piece is properly supported.
Use only grinding wheels approved by RYOBI
Ensure that sparks resulting from use do not create a hazard e.g. do
not hit people, or ignite flammable substances.
Always use protective safety glasses and ear protectors.
Use other personal protective equipment such as gloves, apron and
helmet when necessary.
Never place the tool on the floor or other surfaces while it is running.
Grinding wheels continue to rotate after the tool is switched off.
Never touch the wheel or place it on the floor or other surfaces while
it is rotating.
To ensure safety and reliability, all repairs should be performed
by
an AUTHORIZED SERVICE CENTRE or other QUALIFIED
SERVICE
ORGANIZATION.
MOUNTING THE GRINDING WHEEL (Fig.4,5&6)
WARNING!
Check carefully whether or not there are cracks in the wheel.
Replace a cracked wheel immediately.
1. A
ttach the disc flange (7), the grinding wheel (1) and the clamp nut
(8) to the spindle shaft (9).
Be sure the disc flange is properly seated on the spindle shaft.
2.
Depress the s
pindle
lock button (
1
1) located on the right side of gear case.
3. Using the wrench (10) provided, tighten the clamp nut in a clockwise
direction.
TOOL - LESS WHEEL GUARD (Fig.7b)
Release the wheel guard lock lever (12) then turning the tool-less wheel
guard (2) to the desire position.
OPERATION
KEEP SAFETY GUARDS IN PLACE.
N
NEVER OPERATE THIS ANGLE GRINDER WITHOUT THE TOOLESS
WHEEL GUARD.
EVER C
OVER THE AIR VENTS SINCE THEY MUST ALWAYS BE
OPEN FOR PROPER MOTOR COOLING.
The key to efficient operating is controlling the pressure and surface contact
b
etween the disc and work p
iece. Flat surfaces are ground at an acute
angle, usually 10 to 20 degrees with the work piece. Allow the disc to reach
full speed before starting to grind. Too great an angle causes concentration
MAINTENANCE
of pressure on a small area which may gouge or burn work surface.
After use, check the tool to make sure that it is in good condition.
It is r
ecommended that you take this tool to a Ryobi Authorized Service
Centre for a through cleaning and lubrication at least once a year.
DO NOT MAKE ANY A
DJUSTMENTS WHILE THE MOTOR IS IN
MOTION.
ALWAYS DISCONNECT THE POWER CORD FROM THE SOCKET
B
EFORE CHANGING REMOVABLE OR E
XPENDABLE PARTS
(GRINDING D
ISC, CUTTING DISC ETC), BEFORE LUBRICATING OR
WORKING ON THE UNIT.
WARNING!
NOISE BUILD-UP
AUXILIARY HANDLE (Fig.1)
The auxiliary handle (3) can be attached to either side of the gear box, or the
upper part of the gear box.
The auxiliary side handle on this angle grinder houses the wheel lock nut
wrench. To remove the wheel lock nut wrench from the auxiliary handle, pull
it out by the two lugs on the wrench. When finished with the wrench, slide it
back in to the auxiliary handle with the lugs facing out.
230mm (9")
50 Hz
240 V
2200 W
M14
6000
22.2
mm
7.3
kg
EAG2023CN
x2
SPECIFICATIONS
* Be sure to check the nameplate on the product, because the voltage
is s
ubject to change depending on the area in which the product
is to be used.
APPLICATIONS
(Use only for the purposes listed below.)
MAIN HANDLE
Grinding
Noise (sound pressure level) in the workplace can exceed 85 dB (A). In
this case, sound insulation and hearing protection measures must be taken
by the operator.
SWITCH
STANDARD ACCESSORIES
Aux. handle (3)
Grinding wheel ( 1 )
Wrench (10)
The main handle can be set to any of three positions (0 and 90 degrees) right
and left by pressing the rotary lock button (4) and turning.
lever
Spindle shaft
Livetool Indicator
TM
This tool features a Livetool Indicator
TM
(13) which illuminates as soon as the tool
is connected to the power supply. This warns the user that the tool is connected
to live power and will operate when the switch is pressed.
To ensure safety and reliability, all repairs should be performed
by
an AUTHORIZED SERVICE CENTRE or other QUALIFIED
SERVICE
ORGANIZATION.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
If the supply cord is damaged, it shall be replaced by the manufacturer
or its service agent or similar qualified person in order to avo
id a hazard.
Use the tool only for a
pproved applications. Never use coolants or
water or use the tool as a fixed tool.
Grip the tool securely with both hands while operating.
To switch on the unit - use your index finger to press forward the safety
lock (6) and then press the ON / OFF switch (5).
To switch off the unit - just release the ON / OFF switch (5).
