Change batteries of Laser (Fig. 21
)
Turn Off the Band Saw and switch off the laser beam.
Open the Laser Switch Box Cover by using Philip Head
Screw Driver to loosen that M3 Tapppi
ng Screw (59)
(see Fig. 20)
Replace the 2x Button Cell (AG13 or LR44 or SR44)
i
nto the Button Cell Protection Tube (61). (see Fig. 21)
Close the Laser Switch Box Cover (58) and tighten the
M
3 Tapping Screw (59). (see Fig. 20)
Switch on the laser beam and turn on the Band Saw
for
cut operation.
Use only correct batteries Button Cell. (see Fig. 21)
MOTOR / ELECTRICAL
BRUSHES (Fig. 17)
To prevent accidental starting that could cause possible
serious personal injury, turn off the saw, and unplug thesaw
before working on the band saw.
Remove the screw (48) and washer (20), then pull the
brush (46) off.
Place the new brush in the groove with the plastic tabs
under the saw housing.
Retighten using the washer and screw.
WARNING:
WARNING:
BLADE GUIDES (Fig. 12)
Blade guides may become rounded and worn during use.
Remove the blade guides and file or grind flat.
Replace blade guides when filing or grinding has worn
them down and they can
no longer be properly secured in
place.
WARNING:
WARNING:
Frequently vacuum or blow out sawdust from the motor.
If the power cord is worn, cut or damaged in any way, have
it
replaced immediately by a qual
ified service technician.
Failure to do so could result in serious personal injury.
To avoid fire or electrocution, reassemble electric parts
with
only identical Ryobi replacement parts.Reassemble
exactly
as originally assembled.
There is a brush (46) located inside the saw housing, next
to the lower wheel( 2
9). It helps to protect the tire (47) and
wheel by brushing off saw dust. As the brush becomes
worn out, it will need to be adjusted or replaced.
WARNING:
DRIVE BELT (Fig. 18&19)
To prevent accidental starting that could cause possible
serious personal injury, turn off the saw, and unplug the
s
aw before working on the band saw.
Due to wear or breakage,the drive belt may need to be
replaced. The drive belt (53) is located behind the lower
w
heel (50) of the band saw.
Remove the saw blade and set it aside. See section on
installing and Adjusting the Blade.
P
ull the lower wheel away from the saw housing.
Remove the worn drive belt.
Place new drive belt on the pulley. As you slide the pulley
shaft (51) back into the hole in the saw housing, place
t
he drive belt over the motor pulley (52)
Replace the nut and washer on the pulley shaft a
nd
retighten.
Replace saw blade.
Check thrust bearings and blade guides.
