nₒ No-load speed
n Rated speed
min־¹ Revolutions or reciprocations per minute
Conformity
Double insulation
Wear ear protection
Wear eye protection
Please read the instructions carefully before
starting the product.
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
Recycle raw materials instead of disposing
of as waste. The machine, accessories and
packaging should be sorted for environmental-
friendly recycling.
SPECIFICATIONS
Voltage 240 V 50 Hz
No load speed 14000-31500 min־¹
Input power 1250 W
Plunge depth 55 mm
Collet size 6.35 mm or 12.7 mm
Peak horsepower 1.5 HP
Net weight 4.5 kg
APPLICATIONS
Use your router only for the purposes listed below:
routing grooves, shaping edges, freehand designs,
etc., in wood
chamfering, rabbeting, dadoing, and dovetailing in
wood
routing edges on laminates
FEATURES
Your plunge router is a versatile woodworking tool that
will give you years of trouble-free performance. It is
engineered with the professional in mind, but its ease
of operation allows the amateur to produce work that is
beautiful and precise. As the name implies, your plunge
router can be used for making plunge cuts in workpieces,
routing grooves, edge routing, routing circles, and
freehand routing.
When used with recommended accessories, such as
depth adjustment knob, and straight guide; it becomes
even more versatile. Various types of cutters, both with
and without roller bearings as guides, also add to the
versatility of this tool.
HEAVY DUTY MOTOR
Your router has a powerful motor with sufficient power to
handle tough routing jobs. It delivers 1.5 horsepower for
heavy duty performance.
CHIP SHIELD
A plastic chip shield has been provided on the base of
your router for protection against fl ying dust and chips. It is
designed to fi t the front opening of the router base.
SPINDLE LOCK
The spindle lock secures the spindle so that only one
wrench is needed to loosen collet nut and change cutters.
To operate, push the button whilst loosening the collet.
NOTE: Do not run router with spindle lock engaged or use
as a brake to stop the router.
VARIABLE SPEED
Your router has advanced electronic features, designed to
assist you in getting the maximum use from your router.
By making proper speed selections, your router can be
adjusted to specifi c routing needs.
The variable speed control allows the router to develop a
no load speed that can be adjusted from 14,000 to 31,500
min־¹. The variable speed control selector is conveniently
located on the front of the router.
The electronic feature of your router introduces the
fl exibility of adjusting the motor speed to required job
conditions. An electronic speed control module senses
the load applied to the motor, and increases or decreases
motor voltage to compensate for and maintain desired
RPM. Speed can be set according to the approximate
cutter diameter you will be using and to the hardness of
the material being cut. The best cuts are made when the
cutter is fed through material at the proper rate of feed.
PLUNGE LOCK LEVER
Your router has a plunge lock lever that allows for free
plunging. This feature is very useful when used with the
fine height adjuster quick release mechanism. Unlocking
the plunge lock lever and releasing the fine height adjuster
allows for a smooth, precise plunging action. Once you
reach the desired depth of cut, simply lock the plunge lock
lever. The cutter will then be secured at the desired depth
of cut. After extended use, the plunge lock may wear. If
this happens, you can easily adjust the lever.
