INSTALLATION
SAFETY SENSOR DIAGNOSTIC FEEDBACK
LED FUNCTIONS
RED LED
(TRANSMITTER)
GREEN LED
(RECEIVER)
PROBLEM SOLUTION
ON ON
No problem indicated No action required
OFF OFF
Power head is unplugged
Wires from power head may be
damaged
Wires not connected
Wires connected to the wrong terminal
One or both sensors are defective
Connect to power supply
Replace damaged or broken wires
Connect wires to power head
Connect wires to the correct terminal
Contact customer service for
assistance
OFF ON
One or both sensors are defective Contact customer service for
assistance
ON OFF
The safety sensors are out of alignment
The safety sensors are obstructed
One or both sensors are defective
Safety sensor (transmitter) is not
sending beam
Align the safety sensors
Remove all objects between the
safety sensors
Contact customer service for
assistance
Contact customer service for
assistance
ON FLICKERING
Safety sensor (receiver) is in direct
sunlight
One or both sensors are defective
Change the position of the sensor
(receiver) or reverse the positions of
both sensors (See figure 63)
Contact customer service for
assistance
