9 — English
Clean any debris from the area.
Center the new blade making sure it sits flat on the housing.
Reinstall the washer and blade nut and tighten securely.
Torque the blade nut down clockwise using a torque wrench
(not provided) to ensure the bolt is properly tightened. The
recommended torque for the blade nut is 9.4-10.8 ft-lbs.
NOTE: If a torque wrench is unavailable use the provided
blade wrench to tighten completely and securely.
This replacement part is available from the place of purchase,
or by calling 1-800-525-2579.
WARNING:
Always make sure the blade is correctly installed and
securely fastened before each use. Failure to properly
install the blade may result in serious personal injury.
STORING THE EDGER
Remove the battery pack from the power head before
storing.
Clean all foreign material from the edger.
Store it in a place that is inaccessible to children.
Keep away from corrosive agents such as garden chemi-
cals and de-icing salts.
REPLACEMENT PARTS
Call customer service at 1-800-525-2579 to request replace-
ment parts.
Replacement Blade ...............................................AC04215
MAINTENANCE
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Motor fails to start when switch
trigger is depressed.
Battery is not secure.
Battery is not charged.
To secure the battery pack, make sure the latch
(or latches) snap into place.
Charge the battery pack according to the
instructions included with your model.
CALL US FIRST
For any questions about operating or maintaining your product,
call the Ryobi Help Line!
Your product has been fully tested prior to shipment to ensure
your complete satisfaction.
This product has a Three-year Limited Warranty for personal, family, or house-
hold use (90 days for business or commercial use). For warranty details, visit
www.ryobitools.com or call (toll free) 1-800-525-2579.
