13 - English
FEATURES
PRODUCT SPECIFICATIONS
Motor .................................................. 18 Volt DC
Bar Length .................................................. 10 in.
NOTE: This saw was designed for occasional light
duty use and has some limitations as to what it
can cut.
KNOW YOUR CHAINSAW
See Figure 4.
The safe use of this product requires an
understanding of the information on the product and
in this operator’s manual as well as a knowledge
of the project you are attempting. Before use of
this product, familiarize yourself with all operating
features and safety rules.
RECOMMENDED REPLACEMENT BAR
AND CHAIN COMBINATIONS
Bar Part Number Chain Part Number
311278001 693814001
Fig. 4
FRONT HANDLE
HEX KEY
STORAGE AREA
FRONT HAND
GUARD
SWITCH
TRIGGER
BATTERY PACK
LOCK-OUT
BUTTON
CHAIN OIL
TANK CAP
REAR
HANDLE
GUIDE
BAR
CHAIN
SCABBARD
HEX
KEY
