Ryobi R36LTR10 - Page 9

9
Getting started
1
2
6
Install the battery pack until the latch
clicks into place.
Attach the harness to the harness hanger. Identify the quick-release mechanism
and practice using it before using the product.
7
2
3
1
3
2
1
43
Remove the nut and bolt from the front
handle. Turn the nut counterclockwise
to loosen the handle lock.
Install the safety guard to the bottom side of the silver bracket on the lower shaft.
Insert the tab of the bracket into the opening on the safety guard. Align the screw
to the hole on the safety guard, and turn the screw clockwise to secure the safety
guard in place.
5
8
