Adding oil to the air filter
1. Stop the engine. Engage the chain
brake.
2. Pull the locking tab upwards.
3. Lift the air filter cover straight up to
remove; set aside.
NOTE: Blow or brush as much loose dirt and
sawdust from around the carburettor and
chamber as possible.
Ensure the choke lever is in the full-choke
position to keep the carburettor from being
contaminated.
4. Remove the air filter holder.
