23
English (Original Instructions)
WARNING
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator’s manual. If you
do not understand the warnings and instructions in the
operator’s manual, do not use this product. Call Ryobi
customer service for assistance.
WARNING
The operation of any power tool can result in foreign
objects being thrown into your eyes, which can result
in severe eye damage. Before beginning power tool
operation, always wear safety goggles or safety glasses
with side shields and, when needed, a full face shield.
We recommend Wide Vision Safety Mask for use
over eyeglasses or standard safety glasses with side
shields. Always use eye protection which is marked to
comply with EN 166.
WARNING
Long term inhalation of the engine's exhaust fumes,
chain oil mist and sawdust can result in serious
personal injury.
Save these instructions and pass them on if the saw is to
be used by another person.
SPECIFICATIONS
Model name RCS5133C
Description 51 cc 33 cm (13'') CE saw
Weight - no bar, chain, fuel 5.3 kg
Fuel tank capacity 575 cm
3
Lubricant tank capacity 350 cm
3
Bar length 33 cm
Usable cutting length 305 mm
Chain pitch 8.26 mm (0.325")
Chain gauge 1.27 mm (0.05")
Chain type
0.325" low prole full
complement
Drive sprocket 7 teeth x 0.325''
Engine displacement 51 cm
3
Maximum engine power (ISO
7293)
2.0 kW
Recommended maximum engine
speed with cutting attachment
11,500 r/min
Recommended engine speed
at idling
2,600-3,600 r/min
Specic fuel consumption at
maximum engine power
490 g/kWh
Sound pressure level (ISO 22868)
LpAav: 100dB(A), KpA=3
dB(A)
Sound power level (ISO 22868) 114 dB(A)
Vibration (ISO 22867): Carlton/Oregon
Front handle 8.12 m/s
2
, K=1.5
Rear handle 8.0 m/s
2
, K=1.5
Bar & Chain
Guide bar (no silkscreen)
Oregon part number 130MLBK041
Part number 308276004
Color Black
Chain
Oregon part number 95VPX056P
Part number 900920031
DESCRIPTION
1. Front hand guard/Chain brake
2. Front handle
3. Engine cover
4. Primer bulb
5. Choke lever
6. Chain
7. Starter grip
8. Guide bar
9. Chain catcher
10. Trigger release
11. Chain lubricant cap
12. Silencer
13. Carburettor adjustment
14. Rear handle
15. Throttle trigger
16. Fuel mix cap
17. On/Off switch
18. Starter/Fan housing
19. Spiked bumper
OPERATION
For your safety, study this entire manual before operating
the saw. Pay particular attention to the precautions and
instructions listed in the operator’s manual.
