15
English (Original Instructions)
the carburettor and chamber as possible.
NOTE: Be sure to pull the choke rod out to keep the
carburettor from being contaminated.
3. Using the combination wrench provided or a at blade
screwdriver, remove the screw securing the air lter.
4. Position a at screw driver between the tabs and twist
as shown in the illustration.
5. Lift the air lter off the air lter base.
Choose one of the following cleaning options:
● To lightly clean, tap the filter against a smooth, flat
surface to dislodge most of the saw dust and dirt
particles.
● For a more thorough cleaning, clean in warm
soapy water, rinse, and let dry completely.
● Replace with a new air filter after every 25 hours
of use.
NOTE: An alternative method is to clean the filter with
compressed air (always wear eye protection to avoid
eye injury).
6. Reinstall the air lter, making sure that the tabs on the
air lter are located in channels on the air lter bottom.
7. Reinstall air lter cover assembly. Push down on knob
and rotate clockwise to secure.
8. Clean the pre-lter (D) every 25 tanks of fuel or
sooner, if required. Remove the engine cover (3),
starter assembly (E) and the fan housing bafe (F) for
access to the pre-lter in the engine housing.
NOTE: If you use an air hose for drying, blow through
both sides of filter.
WARNING
Never run the engine without the air lter, serious
damage could result. Make sure the air lter is correctly
placed in the air lter cover before reassembly.
CLEANING THE STARTER UNIT
See gure 64 - 65.
Use a brush or compressed air to keep the cooling vents
of the starter assembly free and clean of debris.
CLEANING THE ENGINE
See gure 66 - 67.
Clean the engine ns and ywheel ns with compressed
air or a brush periodically. Dangerous overheating of the
engine may occur due to impurities on the engine.
WARNING
Never run the saw without all the parts, including the
drivecase cover and starter housing, securely in place.
Because parts can fracture and pose a danger of
thrown objects, leave repairs of the ywheel and clutch
to trained service dealer personnel.
NOTE: Depending on the type of fuel used, the type and
amount of lubricant used, and/or your operating conditions,
the exhaust port and silencer may become blocked with
carbon deposits. If you notice a power loss with your
petrol-powered tool, you may need to remove these
deposits to restore performance. We highly recommend
that only qualied service technicians perform this service.
CHECKING THE FUEL FILTER
See gure 68.
Check the fuel lter (A) periodically. Replace it if
contaminated or damaged.
REPLACING THE SPARK PLUG
See gure 69 - 70.
This engine uses a Champion RCJ4 spark plug with 0.63
mm (0.025 inch) electrode gap. Use an exact replacement
and replace every six months, or more frequently if
necessary.
1. Loosen the spark plug by turning it anticlockwise with
a spanner.
2. Remove the spark plug.
3. Hand thread the new spark plug, turning it clockwise.
NOTE: Be careful not to cross-thread the spark plug.
Cross-threading will seriously damage the engine.
WARNING
Silencer surfaces are very hot during and after
operation of the chainsaw. Keep all body parts away
from the silencer. Serious burns may occur if contact is
made with the silencer.
SPARK ARRESTOR
This product is tted with a spark arrestor screen (inside the
mufer / silencer). If loss of engine power is experienced
the mufer may need to be replaced. Take the tool to a
service dealer to have this maintenance performed.
